MEUS Racing Brushless High Torque Micro Shifting Servo Supports 8.4V/12.5KG 8.4V/8.5KG for 1/24 SCX24 1/18 TRX4M RC Car
-
Estimated Delivery:Jul 23 - Jul 27
-
Free Shipping: On all orders over $60
MEUS Racing Brushless High Torque Micro Shifting Servo Supports 8.4V/12.5KG 8.4V/8.5KG for 1/24 SCX24 1/18 TRX4M RC Car
Key Features
- 1. Suitable for steering servo of SCX24 and TRX4M, and also compatible with shifting servo of 1/24 and 1/18 models.
- 2. Brushless motor provides high-speed response and high torque.
- 3. Supports voltage range of 6-8.4V, providing 8-12.5KG torque.
- 4. High-precision metal gears with high sensitivity, good stability, low noise, better accuracy, and longer service life.
- 5. 8.5KG ME-X8 servo and 12.5KG ME-X12 servo are not waterproof and water-resistant.
Specifications:
Servo Arm Material: Metal
Product Number: ME-X8
- Operating Voltage: 4.8~8.4VDC
- Max. Torque-6.0V: ≥ 6 kg.cm
- Max. Torque-7.4V: ≥ 7.5 kg.cm
- Max. Torque-8.4V: ≥8.5 kg.cm
- No Load Speed-6.0V: ≦0.07sec/60°
- No Load Speed-7.4V: ≦0.06sec/60°
- No Load Speed-8.4V: ≦0.058sec/60°
- Operating Travel Angle: 180°+10°(500~2500 us)
- Motor Type: Coreless motor
- Horn Gear Spline: 25T/∅4.90mm
- Gear Set Material: Metal gear
- Weight: 21.6+ 0.5g
- Size: 23*12*27mm
Product Number: ME-X12
- Operating Voltage: 4.8~8.4VDC
- Max. Torque-6.0V: ≥ 8 kg.cm
- Max. Torque-7.4V: ≥ 11 kg.cm
- Max. Torque-8.4V: ≥12.5 kg.cm
- No Load Speed-6.0V: ≦0.07sec/60°
- No Load Speed-7.4V: ≦0.06sec/60°
- No Load Speed-8.4V: ≦0.06sec/60°
- Operating Travel Angle: 180°+10°(500~2500 us)
- Motor Type: Brushless motor
- Horn Gear Spline: 25T/∅4.90mm
- Gear Set Material: Metal gear
- Weight: 21.6+ 0.5g
- Size: 23*12*27mm
Package List
- 1 × 8.5KG ME-X8 servo
- 1 × 12.5KG ME-X12 servo (option)
- 1 × Metal Servo Arm for SCX24 (option)
- 1 × Metal Servo Arm for TRX4M (option)
